Low cost borescope
Available to observe narrow space
- You can visually inspect nondestructively the inside of a narrow space where human eyes can not reach directly.
- Field of view angle 30°（Side）
Borescope φ2.7mm 175mm BAL-32718 (30°)
Specification
General Specification
- Model Number
- BAL-32718
- Operating Temperature
- -15~65℃
- Water Resistance
- Insertion part is waterproof Other parts drip-proof（*） ※No trouble Gasoline, Machine oil, 5% Saline (salt water) is attached
- Field of view
- 30° （Side）
- Tube
- 175mm
- Field of view angle
- 55°
- Tube diameter
- φ2.7mm
You can purchase only what you need for your needs.
| If you want a handy and easy observation |
Easy to hold, convenient to use
|
Handy camera for borescope
＋ Variable Magnification Camera Adapter Lens ＋ LED lighting for borescope (3W) |
 |
| If you want to shoot using a high definition camera |
Images with no display delay (suitable for inspection and work)
|
High-definition camera
＋ Variable Magnification Camera Adapter ＋ LED lighting for Borescope Powered |
 |
| If you want to take pictures using a USB camera |
When you need to store a lot of video, or when you need to process images using software in addition to observing
|
USB camera
＋ Variable Magnification Camera Adapter ＋ LED lighting for Borescope Powered |
 |
Other options
|
Handy lighting for borescopes
Handy LED lighting
for borescopes (battery-powered) LED-BH3 ・Handy LED lighting
for borescopes ・1 lithium battery included as standard ・Lithium charger sold separately |
 |
Camera adapter for connecting a C-mount camera to a borescope
|
・Camera adapter for connecting
a C-mount camera to a borescope or fiberscope ・Adapter lens allows magnification and focus adjustment (distance from subject is infinity to 3mm) ・Can be connected to 28mm to 32mm eyepieces |
 |
LED lighting for borescope with connected camera
|
・Coaxial lighting that can be
attached to various borescopes and fiberscopes with M10 and P=0.5. Light intensity can be visualized with a 7-segment display. |
 |
Images captured by the high-definition camera are saved on the included microSD card.
|
By connecting a high-definition camera to the HR-MINI,
you can record still images and videos onto the microSD card that comes with the HR-Mini. |
 |
Convenient optional camera stand
|
|
 |
|
|
 |
